Post Info TOPIC: Wondering about model differences or year model????


Super Guru

Status: Offline
Posts: 8557
Date:
Wondering about model differences or year model????
Permalink



I occasionally get asked about model names and codes. I just found the following in a supplementary service manual I was looking through and hope it is helpful.

Pity it doesn't include dates of manufacture and frame numbers hmm

Also see this thread - https://ttr250.activeboard.com/t55938126/ttr250-catalogue-showing-different-models-and-years/

Brian

Model names and codes and catalogue numbers .jpg

Early model numbers with dates and possibly frame numbers:

Models with dates.jpg



__________________

Exeter, Devon, UK

http://www.ttr250.com  - The one and only dedicated TTR250 FAQ!


TIP: For easy viewing bookmark the "Recent Posts" view - http://ttr250.activeboard.com/p/recent/

DC


Veteran Member

Status: Offline
Posts: 57
Date:
RE: Model names and codes and catalogue numbers
Permalink



Thanks Brian. I have often wondered what the 'RS' on mine stands for. Are there any differences between them?

__________________

Paul, Surrey UK.

TTROOKIES.  Three Blokes. Three TTRs.  All the gear and no idea.



Guru

Status: Offline
Posts: 932
Date:
Wondering about model differences or year model????
Permalink



Just thought id share this usefull info







Model Identification


The 10th number a long from the left of the 17 digit vin is the year.
EG: 2 is 2002

Note:
Before 2001 the 10th number was a letters
EG: 1999 model will be a X and a 1998 model will be a W

Most manufacturers release their bikes BEFORE the Model year. It is normal to find (say) a 2004 model with a 10/2003 build date.
Soooo! If you are not sure, please ask!!

This can be particularly important for older bikes if you want to get the correct cable or bearing....

Model Identification for Motorcycles released outside Australia: Quite often there are subtle differences between the models released in different markets. In general, the basic model code will be the same, but may vary on details such as carburation and running gear such as lights, indicators and guards. For example, a model from Japan will usually include pre heaters in the carby and may be jetted differently to account for the octane rating of the fuel in a local market.

Go to our ebay store NOW



__________________

YAMAHA ROCKS!!!!!!

TTR250ACTIVE''BORED'' ADDICT!

Favourite quote: To be old & wise first you must be young & dumb!

My own: Your never too young to learn an old trick! :)



Guru

Status: Offline
Posts: 932
Date:
Permalink


Thought i would share some info that i have acquired from mechanics,yamaha etc. So far the only differences yamaha made to the motors are eg:

Clutch plates/boss and basket some have 6 some have 5 & some 7 friction plates. Both are interchangable provided you use the whole cluch assembly & 99 clutch cover. The clutch plates all interchange.

 Electric start on some models can be interchanged using all the electric start components.

Compression ratio on Raid models although any head is interchangeable.

Other than that i have'nt found any differences between any model ttr 250. If anyone would like to add to this or enlighten me feel free to do so.Cheers



-- Edited by barra8 on Saturday 2nd of February 2013 07:42:04 PM

__________________

YAMAHA ROCKS!!!!!!

TTR250ACTIVE''BORED'' ADDICT!

Favourite quote: To be old & wise first you must be young & dumb!

My own: Your never too young to learn an old trick! :)



Super Guru

Status: Offline
Posts: 8557
Date:
Permalink


The bit about different compression ratios surprised me. I hadn't noticed that on the specifications before - see http://www.ttr250.com/#Specifications

The part number for the cylinder head for the first 4GY1 and 4GY3 models are different to the 4GY5, 4RR1, 4RR2, and 4WA1 but I have no idea what the difference is! The valves all have the same part number.

So, if you have a very early TTR then the best way of tuning it is to put on a later cylinder head wink

Brian



__________________

Exeter, Devon, UK

http://www.ttr250.com  - The one and only dedicated TTR250 FAQ!


TIP: For easy viewing bookmark the "Recent Posts" view - http://ttr250.activeboard.com/p/recent/



Guru

Status: Offline
Posts: 932
Date:
Permalink


TTRfan wrote:

Model differences:

Most white metal-tanked TTRs have a digital speedo and therefore have a gearbox with an extended transmission/sprocket shaft to take the speedo magnet.

They also mostly have 6-plate clutches and a narrower clutch cover and therefore less oil than later 7-plate models. Easy to tell the difference as the later covers have Yamaha stamped on it them.

6-plate cover (stamped 1000cc) below:



7-plate cover (stamped 1100cc) below:




Oh and if it had a less aggressive cam (and cam timing) would'nt that change the ratio as the valves would be opening for a shorter period and not as far open???? Just going off the capacity of what it can suck through.

 Your theory on the ports is a good one and what i think it must be. Don't know why i didn't think of that aww



__________________

YAMAHA ROCKS!!!!!!

TTR250ACTIVE''BORED'' ADDICT!

Favourite quote: To be old & wise first you must be young & dumb!

My own: Your never too young to learn an old trick! :)



Guru

Status: Offline
Posts: 932
Date:
Permalink


I wasn't counting the plates on the boats site as it's the same pic for all ttr's. I was looking at the number of clutch plates needed for assembly as it tells you this under the pics.

I have a pic of my clutch plates (white bike) and there is 6 so not sure who is right on tthe clutch subject.

On the cam subject i just thought that maybe on the down stroke the valves would open more or less with different cam letting more or less air through. Maybe i'm on the wrong track though smile




-- Edited by barra8 on Monday 23rd of July 2012 11:04:30 PM

__________________

YAMAHA ROCKS!!!!!!

TTR250ACTIVE''BORED'' ADDICT!

Favourite quote: To be old & wise first you must be young & dumb!

My own: Your never too young to learn an old trick! :)



Guru

Status: Offline
Posts: 932
Date:
Permalink


TTRfan wrote:
barra8 wrote:

I wasn't counting the plates on the boats site as it's the same pic for all ttr's. I was looking at the number of clutch plates needed for assembly as it tells you this under the pics.

I have a pic of my clutch plates (white bike) and there is 6 so not sure who is right on tthe clutch subject.



I think we are actually agreeing biggrin

White TTR - 6 friction plates (your pic confirms) and narrower clutch cover

Blue TTR - 7 friction plates (my pic confirms) and wider clutch cover

Brian wink


 Oh sorry brian i should have read your mesg better. Just counted your plates and missed one lol. That's weird that you have 7 as i have'nt found this info on the boats site. Have'nt checked all models yet though.Who knows maybe there listing is wrong??? You would think that they would have it right by now though???



So did you get my point i made about the cam or do you still think i'm off with the fairies?biggrin

 My clutch is aftermarket so maybe why it's thinner on the pressure plate??



Oh i think i know why you have 7. Is one of those plates a friction plate???



Ps. hope i'm not getting on your nerves Brian just trying to get to the bottom of it all.



-- Edited by barra8 on Monday 23rd of July 2012 11:37:06 PM



-- Edited by barra8 on Monday 23rd of July 2012 11:41:54 PM

__________________

YAMAHA ROCKS!!!!!!

TTR250ACTIVE''BORED'' ADDICT!

Favourite quote: To be old & wise first you must be young & dumb!

My own: Your never too young to learn an old trick! :)



Super Guru

Status: Offline
Posts: 8557
Date:
Permalink


Model differences:

Most white metal-tanked TTRs have a digital speedo and therefore have a gearbox with an extended transmission/sprocket shaft to take the speedo magnet.

They also mostly have 6-plate clutches and a narrower clutch cover and therefore less oil than later 7-plate models. Easy to tell the difference as the later covers have Yamaha stamped on it them.

6-plate cover (stamped 1000cc) below:


7-plate cover (stamped 1100cc) below:




__________________

Exeter, Devon, UK

http://www.ttr250.com  - The one and only dedicated TTR250 FAQ!


TIP: For easy viewing bookmark the "Recent Posts" view - http://ttr250.activeboard.com/p/recent/



Guru

Status: Offline
Posts: 932
Date:
Permalink


Yeah it's weird how the valves seem to fit all models but the compression ratio is different on the raid model????confuse How can that be?? cam timing??? shorter stroke?  That subject has me fooled lolbiggrin  Wonder if anyone here knows???



__________________

YAMAHA ROCKS!!!!!!

TTR250ACTIVE''BORED'' ADDICT!

Favourite quote: To be old & wise first you must be young & dumb!

My own: Your never too young to learn an old trick! :)



Super Guru

Status: Offline
Posts: 8557
Date:
Permalink


The bore and stroke of all TTR models is the same so it is likely that the lower CR of the early models is achieved by there being a bigger combustion volume in the cylinder head. Cam timing wouldn't affect the CR.

The wiring looms on the Raid and white metal-tanked OEs are different to the plastic tank models. They incorporate connections for the digital speedo head and sender unit. Also the headlight connection on the loom is different at least as far as the European blue model is concerned as it incorporates an extra wire for the parking light in the headlight.

At least one Raid model has a clever relay circuit that only allows power to the lights when the engine has started. I wasted a lot of time trying to get a headlight to work on of those models until I sussed what was happening. I am not particularly confident with bike electrics disbelief



__________________

Exeter, Devon, UK

http://www.ttr250.com  - The one and only dedicated TTR250 FAQ!


TIP: For easy viewing bookmark the "Recent Posts" view - http://ttr250.activeboard.com/p/recent/



Super Guru

Status: Offline
Posts: 8557
Date:
Permalink


barra8 wrote:

 I don't like to correct you brian but it seems the earlier models had 6 clutch plates eg

1999: http://www.boats.net/parts/search/Yamaha/Motorcycle/1999/TTR250LC/CLUTCH/parts.html

The 2006 model used 6 too eg. http://www.boats.net/parts/search/Yamaha/Motorcycle/2006/TT-R250%20-%20TTR250V/CLUTCH/parts.html

The difference i have found so far is the 2005 model with 5 clutch plates eg.   http://www.boats.net/parts/search/Yamaha/Motorcycle/2005/TTR250%20-%20TTR250TC/CLUTCH/parts.html



Oh and if it had a less aggressive cam (and  or cam timing) would'nt that change the ratio as the valves would be opening longer???? Your theory on the ports is a good one and what i think it must be. Don't know why i didn't think of that aww


I don't mind being challenged wink

If you count the friction plates in the fiche pics on the boats.net links you will see that they are all 7 plate. See the pic of a clutch assembly from a blue TTR below showing clearly the 7 friction plates:


I haven't got a pic of a white TTR clutch assembly but I promise that they only have 6 friction plates.

Regarding valve timing, all valves on a 4T will be fully closed at TDC on the combustion cycle.

Brian



__________________

Exeter, Devon, UK

http://www.ttr250.com  - The one and only dedicated TTR250 FAQ!


TIP: For easy viewing bookmark the "Recent Posts" view - http://ttr250.activeboard.com/p/recent/



Super Guru

Status: Offline
Posts: 8557
Date:
Permalink


barra8 wrote:

I wasn't counting the plates on the boats site as it's the same pic for all ttr's. I was looking at the number of clutch plates needed for assembly as it tells you this under the pics.

I have a pic of my clutch plates (white bike) and there is 6 so not sure who is right on tthe clutch subject.



I think we are actually agreeing biggrin

White TTR - 6 friction plates (your pic confirms) and narrower clutch cover

Blue TTR - 7 friction plates (my pic confirms) and wider clutch cover

Brian wink



__________________

Exeter, Devon, UK

http://www.ttr250.com  - The one and only dedicated TTR250 FAQ!


TIP: For easy viewing bookmark the "Recent Posts" view - http://ttr250.activeboard.com/p/recent/



Super Guru

Status: Offline
Posts: 8557
Date:
Permalink


barra8 wrote:
That's weird that you have 7 as i have'nt found this info on the boats site. Have'nt checked all models yet though.Who knows maybe there listing is wrong??? You would think that they would have it right by now though???

 So did you get my point i made about the cam or do you still think i'm off with the fairies?biggrin


Boats.net have the number of friction plates right for the blue model - see screen print below:
Boats extract.jpg

The CR is measured at TDC when all valves are closed - see the formula below. The only way the early models can have a lower CR is that they have a deeper combustion chamber in the head wink

Formula

The ratio is calculated by the following formula:

\mbox{CR} = \frac { \tfrac{\pi}{4} b^2 s + V_c } {V_c}, where
b\; = cylinder bore (diameter)
s\; = piston stroke length
V_c\; = clearance volume. It is the volume of the combustion chamber (including head gasket). This is the minimum volume of the space at the end of the compression stroke, i.e. when the piston reaches top dead center (TDC). Because of the complex shape of this space, it is usually measured directly rather than calculated.
I think we have probably got to the bottom of it now biggrin
Brian


__________________

Exeter, Devon, UK

http://www.ttr250.com  - The one and only dedicated TTR250 FAQ!


TIP: For easy viewing bookmark the "Recent Posts" view - http://ttr250.activeboard.com/p/recent/



Super Guru

Status: Offline
Posts: 2608
Date:
Permalink


TTRfan wrote:

 The only way the early models can have a lower CR is that they have a deeper combustion chamber in the head wink
Brian

 That ain't necessarily so, Brian. no

The depth of the combustion chamber certainly has a bearing on the compression ratio of an engine, granted.

However, the MAIN method of altering an engine's CR is by fitting a different piston. confuse

An engine manufacturer makes one engine that is suitable for many uses. For example, BSA Gold Stars were made and used for trials, scrambles, road, racing, sprinting, etc. A buyer could specify the tune of an engine when ordering to satisfy his demands. BSA would have a selection of different pistons that altered the compression ratio by the shape of the piston head. The distance between the centre of the little end and the top of the piston crown can be quite different to give a variation of ratios. A high compression racing piston may have, say 100mm height, a low compression trials piston may have a mere, say 90 mm height. The 10 mm difference gives a different CR for each piston. The "swept" volume is being altered by the piston shape.

My T100 started originally on 8:1, but pistons giving ratios between 5:1 and 10:1 were readily available from Hepolite and others. The cylinder head and valves were the same on all CRs. smile

Martyn (pedant)



__________________

You're never too old to learn something stupid

East Budleigh. Devon



Super Guru

Status: Offline
Posts: 8557
Date:
Permalink


Sorry Martyn - I didn't make myself clear - so what's new eh?  no

I was working from the basis that all the TTR pistons are the same.

So the first TTRs with the apparently 8.5:1 CR have a piston with part number 4GY-11631-00-C0 - for the OE see http://www.megazip.ru/ru/bike/yamaha/view/1086/2710/51744#g51746

For the Raid see: http://www.megazip.ru/ru/bike/yamaha/view/1086/2716/51744#g51746

And the later blue models have the exact same part number - see http://www.boats.net/parts/search/Yamaha/Motorcycle/2003/TTR250%20-%20TTR250R/CRANKSHAFT%20PISTON/parts.html

If I am right that all TTRs use the exact same standard Yam OEM piston then the different CRs can only be explained by a difference in the combustion chamber in the head.

As always, I am happy to be corrected wink

Brian





__________________

Exeter, Devon, UK

http://www.ttr250.com  - The one and only dedicated TTR250 FAQ!


TIP: For easy viewing bookmark the "Recent Posts" view - http://ttr250.activeboard.com/p/recent/



Guru

Status: Offline
Posts: 932
Date:
Permalink


Okay well i see what you mean about the cylinder volume capacity wont change by fitting a different cam. Just thought it may let less or more in with a different cam. Maybe i'm on the wrong track as i guess the capacity would be the same,it would just change the flow of the engine. Thanks for the ideas and solutions to questions Brian and others...



__________________

YAMAHA ROCKS!!!!!!

TTR250ACTIVE''BORED'' ADDICT!

Favourite quote: To be old & wise first you must be young & dumb!

My own: Your never too young to learn an old trick! :)



Veteran Member

Status: Offline
Posts: 66
Date:
Permalink


I am a bit late with this Barra8. But worth a look        http://en.wikipedia.org/wiki/Compression_ratio

Sorry I have not linked it, having computer problems, I am knackered and I want to go to bed. Nite Nite.



-- Edited by Cubber on Tuesday 24th of July 2012 10:39:36 PM

__________________


Guru

Status: Offline
Posts: 932
Date:
Permalink


Thanks for the info,but maybe time to get back to the subject.

So far the differences are

Clutch plates,boss & basket some have 5 some 6 some 7. Both are interchangable provided you use the whole clutch assembly with the 99 clutch cover.All clutch plates interchange.

The 1993-1998 electric start can be interchanged with 99-2013 parts

Compression ratio on Raid models.

Most white metal-tanked TTRs have a digital speedo and therefore have a gearbox with an extended transmission/sprocket shaft to take the speedo magnet.

They also mostly have 6-plate clutches and a narrower clutch cover and therefore less oil than later 7-plate models. Easy to tell the difference as the later covers have Yamaha stamped on it them.

The obvious eg. wiring,plastic tank-metal ect..

Other than that i have'nt found any differences between any model ttr 250. If anyone would like to add to this or enlighten me feel free to do so.Cheers



-- Edited by barra8 on Saturday 2nd of February 2013 07:20:02 PM

__________________

YAMAHA ROCKS!!!!!!

TTR250ACTIVE''BORED'' ADDICT!

Favourite quote: To be old & wise first you must be young & dumb!

My own: Your never too young to learn an old trick! :)



Guru

Status: Offline
Posts: 932
Date:
Permalink


Oh... maybe someone removed it or it is from an EARLY model as my old 1994 0r 1995 (originally purple frame)has the strenghtened frame also. I just checked.


......................

Jarrah.



-- Edited by barra8 on Saturday 2nd of February 2013 08:32:04 PM

__________________

YAMAHA ROCKS!!!!!!

TTR250ACTIVE''BORED'' ADDICT!

Favourite quote: To be old & wise first you must be young & dumb!

My own: Your never too young to learn an old trick! :)



Guru

Status: Offline
Posts: 932
Date:
Permalink


Engine differences between 1992-1999 and 1999-2006

All cylinder barrels are the same

All heads are interchangable (raid model different compression ratio but still fits). Also the breather pipe is on the 1999-2006 head but not hard to fit a two piece joiner and pipe  (if fitting the 1993-1998 bottom end to a 1999-2013 head)  or the 1992-1999 head cover plate. *Edited Also while on the head cover plate i forgot to mention that the older models don't have the bump stop fitted.

The only differences with engines between any model from 1992-2012 is mentioned below.

You can order 1999-2006 parts unless its clutch boss & basket as these are different with the engines ie. 1999-2012 TTr 250 has 7 clutch plates 1992-1998 has 6.

All clutch and friction plates are the same in any model mentioned and will interchange.

Note: Some early models had 5 clutch plates

Interestingly enough if you fit all the components from the 1999-2006 eg. clutch boss and basket,clutch cover (pictured below) you can upgrade to the 7 plates no problem.

The good points to this would be that you would get the higher oil capacity (see below) and the added bonus of an extra clutch plate or two.

1992-1999 cover stamped 1000 cm/3 (see below)




1999-2006 plate cover (stamped 1100 cm/3 below:




1992-1999 6 clutch plates (see below)





1999-2006 7 clutches plates (see below)


The rotor casing is different from 1993-1998 & 1999-2013 but all starter components interchange aswell as the casing.

Also the white metal-tanked TTRs have a digital speedo and therefore have a gearbox with an extended transmission/sprocket shaft to take the speedo magnet.

..........................................................................................................................

Frame differences:

The 1993-1998 frame has two rubber mounts at the front & bolts on at the rear,whereas the 1999-2013 has a rubber mount underneath the tank,bolts on at the front & has a rubber holding it down.

As Brian brought into light ''some'' 1993-1998 frames do not have strengthening fillets at the rear shocky mount. All 1999-2013 on the otherhand have the strengthening fillets.

.................................................................................................................................

Carby differences:

In Australia the 1993-1998 carb has #48 pilot & #147 main jet. Whereas the 1999-2013 models have #50 pilot & #147 main jet. It has been suggested by Brian that the change to #50 pilot was around 1996 for the UK.

The slider arm on the 1993-1998 & 1999-2013 carby is slightly different but is still interchangable.

The top cover on the 1999-2013 carb has lipped edges whereas the 1993-1998 does'nt. Both are interchangable.

...............................................................................................................................................

Front axle difference:

The 1999-2013 has a different axle than the 1993-1998 as the 1993-1998 has to accomadate the speedo drive.

.........................................................................................................................................................................

Headlight:

Headlight bracket...

Note: Any speedo bracket from 1993-2012 should fit but i used a 1994 one as it was lighter. You can see this in the pic below...


...................................................................................................................................................................

Wiring:

Some blue models have a different headlight capacity so therefore seem to have different wiring harness.

Speedo wires fitted to the 1993-1998 models

.................................................................................................

I think that's all or i will start to go into different country differences.

The US model has a different headlight plug than the Australian or UK models but can be chopped & joined.

Brake light, blinkers ect. not fitted to US models (obvious).They still have the wiring needed in the harness (as far as i can tell)

The US headlight...awwawwawwawwaww...

Note: You will notice i left colour changes out as these are'nt important. (to me anyway)

............................

Jarrah.



-- Edited by barra8 on Saturday 2nd of February 2013 11:43:49 PM

__________________

YAMAHA ROCKS!!!!!!

TTR250ACTIVE''BORED'' ADDICT!

Favourite quote: To be old & wise first you must be young & dumb!

My own: Your never too young to learn an old trick! :)



Super Guru

Status: Offline
Posts: 8557
Date:
Permalink


First time I have spotted this frame difference! You can see from the first pic of the purple frame where the frame had cracked and been re-welded. This must have been a problem for Yamaha to have added the fillets on the later metallic blue frames.

Brian

Frame differences - purple frame.jpg

Frame differences - metallic blue frame.jpg



__________________

Exeter, Devon, UK

http://www.ttr250.com  - The one and only dedicated TTR250 FAQ!


TIP: For easy viewing bookmark the "Recent Posts" view - http://ttr250.activeboard.com/p/recent/



Guru

Status: Offline
Posts: 932
Date:
Permalink


Ahr yes that is another difference that went unnoticed. Good spotting Brian

I have not looked at this thread in ages smile

........................

Jarrah.



__________________

YAMAHA ROCKS!!!!!!

TTR250ACTIVE''BORED'' ADDICT!

Favourite quote: To be old & wise first you must be young & dumb!

My own: Your never too young to learn an old trick! :)



Super Guru

Status: Offline
Posts: 8557
Date:
Permalink


Maybe some geographical differences?

Just looking back through my photo albums and found a 1994 Raid frame without the fillets.

Raid frame.jpg

But the other purple frames are about a 50/50 mix. Some have fillets others don't confuse

I jumped to a wrong conclusion based on one frame disbelief

Brian



__________________

Exeter, Devon, UK

http://www.ttr250.com  - The one and only dedicated TTR250 FAQ!


TIP: For easy viewing bookmark the "Recent Posts" view - http://ttr250.activeboard.com/p/recent/



Guru

Status: Offline
Posts: 932
Date:
Permalink


It's okay Brian we can't always be right the first time lol i edit all the time hahaha biggrin

I like how the frame in the pic above has been sprayed, why did'nt i think of that when i sprayed my frame lol it may have saves some work biggrinbiggrinbiggrin

I might add a few things to this as there is heaps of other differences. It can wait though,in the meantime anyone else want to add to the topic??

......................

Jarrah.



__________________

YAMAHA ROCKS!!!!!!

TTR250ACTIVE''BORED'' ADDICT!

Favourite quote: To be old & wise first you must be young & dumb!

My own: Your never too young to learn an old trick! :)



Guru

Status: Offline
Posts: 932
Date:
Permalink


If anyone wants to add the Raid differences be my guest but i'm not interested in them personally.

.........................

Jarrah.



__________________

YAMAHA ROCKS!!!!!!

TTR250ACTIVE''BORED'' ADDICT!

Favourite quote: To be old & wise first you must be young & dumb!

My own: Your never too young to learn an old trick! :)

Page 1 of 1  sorted by

Quick Reply

Please log in to post quick replies.



Create your own FREE Forum
Report Abuse
Powered by ActiveBoard
